60220D

Adjustable LCD Arm (Desk Top Mount)

This desk top mount adjustable LCD monitor arm is designed to be small in size, lightweight, of high quality appearance and competitively priced. The design incorporates effortless height, tilt and rotation adjustment of the monitor. Ruggedly constructed from light weight aluminum alloy arm parts with quality surface coating and provision for internal housing of monitor cabling.
  • Patented counter force lift design incorporating knob-less, quiet and smooth dampened operation. Enhances user comfort and convenience through effortless adjustment of the screen position for optimum viewing angle.
  • 90° vertical angle adjustment of the arm allows adjustment for the most comfortable viewing height. Minimizing user fatigue.
  • 360° arm side to side rotation and 180° display side to side rotation.
  • 90° portrait/landscape pivot oration.
  • Models are available for loading range from 2.5 kgs (5.5 lbs) to 13 kgs (28.6 lbs).
  • Counter force balanced monitor tilt 87° up or 25° down from vertical plane.
  • Grommet mounting base can be mounted on desk top or horizontal surface.
  • Conform to the VESA 75mm hole pattern, VESA 100mm adapter is optional.
  • Arm internal housing for computer cabling.
  • OEM mounts bracket can be manufactured to meet your specific requirement.

Range Of Motion :

90° portrait landscape
90° Arm vertical adjustment
180° monitor side to side rotation
360° Arm side to side rotation
Up 85° Down 25° monitor tilt adjustment
Cable management

Configure Options

Pivot head

VESA plate

Adjustble Arm

Extension/Swing Arm

Desk Top Mount
